IC-KP2-2HB17-2V1D
Commands
2014-02
61
Configuration store (CS)
Command:
Response:
The configuration store (CS) command allows you to store the last command sent to the R/W
head in the non-volatile memory of the IDENTControl Compact. The R/W head executes the
command automatically again if the power supply is interrupted or the IDENTControl Compact
is reset.
<Mode>='1' activates the mode.
<Mode>='0' deactivates the mode.
Configuration store is deactivated by default.
Byte Contents Bit no.
7 6 5 4 3 2 1 0
Byte 2 Command code (17h) 0 0 0 1 0 1 1 1
Byte 3 Reserved/Ident channel/Toggle bit - - - - <Channel> <T>
Byte 4 Mode 0 0 0 0 0 0 0 <Mode>
Byte 5 not used - - - - - - - -
Byte 6 not used - - - - - - - -
Byte 7 not used - - - - - - - -
Byte 8 not used - - - - - - - -
Byte 9 not used - - - - - - - -
Byte Contents Bit no.
7 6 5 4 3 2 1 0
Byte 2 Command code (17h) 0 0 0 1 0 1 1 1
Byte 3 Reserved/Ident channel/Toggle bit - - - - <Channel> <T>
Byte 4 Status <Status>
Byte 5 Reply counter <ReplyCounter>
Byte 6 not used - - - - - - - -
Byte 7 not used - - - - - - - -
Byte 8 not used - - - - - - - -
Byte 9 not used - - - - - - - -
