IC-KP2-2HB17-2V1D
Commands
2014-02
55
Response: Type IPH-... read/write head on channel 1
Alternative response: No read/write head on channel 1
Example: Read tag
Prerequisites:
■
The tag type IPC03 is set.
■
One type IPH-… read/write head is connected to channel 1.
Command: Read two double words starting from address 0 on channel 1
Confirmation
Response: Type IPC03 tag is located in front of the read/write head, the highlighted
part depends on the content of the tag
Alternative response: No tag in front of read/write head
04:02:00:02
04 Repeat command code CT (change tag)
02 Reserved/Channel (1), toggle bit 0b
00 Status 0 (command executed without error)
02 Reply counter
04:02:06:02
04 Repeat command code CT (change tag)
02 Reserved/Channel (1), toggle bit 0b
06 Status 6 (hardware error)
02 Reply counter
10:22:00:00
10 Command code SR (single read words)
22 Number of double words (2) / channel (1), toggle bit
00:00 Address of double words (0000)
10:22:FF:01
10 Repeat command code SR (single read words)
22 Number of double words (2) / channel (1), toggle bit
FF Status FFh (processing command)
01 Reply counter
10:22:00:02:31:32:33:34:35:36:37:38
10 Repeat command code SR (single read words)
22 Number of double words (2) / channel (1), toggle bit
00 Status 0 (command executed without error)
02 Reply counter
31:32:33:34:35:36:37:38 Data
10:02:05:02
10 Repeat command code SR (single read words)
02 Number of double words (0) / channel (1), toggle bit
05 Status 5 (no tag in the detection range)
02 Reply counter
