2014-02
114
IC-KP2-2HB17-2V1D
Appendix B
Class attributes (instance 0)
Output instance attributes (instances 100d-112d)
Output instance 100d - 8 bytes
Output instance 101d - 12 bytes
Output instance 102d - 32 bytes
Output instance 103d - 60 bytes
Output instance 104d - 32 bytes
Output instance 105d - 48 bytes
Attribute ID Name Data type Data content Access
authorization
1 Revision UINT 2 Ge t
2 Max. instance UINT 162 Ge t
100 I/O output instance USINT 100 Get / Se t
101 I/O output produce length UINT 8 Ge t
102
I/O input instance
1)
USINT 150 Ge t
103 I/O input consume length UINT 8 Ge t
Table 12.1 1) I/O input instance = I/O output instance + 50d
Attribute ID Name Data type Data content Access
authorization
3 Output data USINT
[0-248]
0 Ge t
Bytes Class, instance, attribute Description
0 - 7 64h, 06d, 01h Mixed mode [8]
Bytes Class, instance, attribute Description
0 - 11 64h, 06d, 02h Mixed mode [12]
Bytes Class, instance, attribute Description
0 - 31 64h, 06d, 03h Mixed mode [32]
Bytes Class, instance, attribute Description
0 - 59 64h, 06d, 04h Mixed mode [60]
Bytes Class, instance, attribute Description
0 - 7 64h, 01d, 01h Channel 1 [8]
8 - 15 64h, 02d, 01h Channel 2 [8]
16 - 23 Reserved Reserved
24 - 31 Reserved Reserved
Bytes Class, instance, attribute Description
0 - 11 64h, 01d, 02h Channel 1 [12]
12 - 23 64h, 02d, 02h Channel 2 [12]
