8.2.2 Overview of the Commands
8.2.2.1 Get Lists and Flags (Get_LPS, Get_LAS, Get_LDS, Get_Flags)
(GET_LISTS)
With this call, the following entries are read out of the AS-i/PROFIBUS gateway:
• The list of active AS-i slaves (LAS)
• The list of detected AS-i slaves (LDS)
• The list of projected AS-i slaves (LPS)
• The flags according to the AS-i slave specification
Pok Periphery_Ok
S0 LDS.0
AAs Auto_Address_Assign
AAv Auto_Address_Available
CA Configuration_Active
NA Normal_Operation_Active
APF APF
OR Offline_Ready
Cok Config_Ok
AAe Auto_Address_Enable
OL Offline
DX Data_Exchange_Active
8.2.2.2 Get Flags (GET_FLAGS)
With this call, the following entry is read out of the AS-i/PROFIBUS gateway: the
flags according to the AS-i slave specification.
Values for command
Command value meaning Req Len Res Len
GET_LISTS 30
16
Get LDS, LAS, LPS, Flags 2 29
GET_FLAGS 47
16
Get_Flags 2 5
GET_DELTA 57
16
Get list of config. diff. 2 10
GET_LCS 60
16
Get LCS 2 10
GET_LAS 45
16
Get_LAS 2 10
GET_LDS 46
16
Get_LDS 2 10
GET_LPF 3E
16
Get_LPF 2 10
GET_LOS 61
16
GET_LOS 2 10
SET_LOS 62
16
SET_LOS 10 2
GET_TECA 63
16
Get transm.err.counters 2 34
GET_TECB 64
16
Get transm.err.counters 2 34
GET_TEC_X 66
16
Get transm.err.counters 4 ≥3
Request
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 47
16
