8.2.4.6 Get Extended Permanent Configuration (GET_PCD)
This call reads the following configuration data (configured data) of an addressed
AS-i slave stored on the EEPROM of the AS-i master:
• I/O configuration
• ID code
• Extended ID1 code
• Extended ID2 code
The configuration data are specified by the manufacturer of the AS-i slave.
Meaning of bit B:
B = 0 Single AS-i slave or A-slave
B = 1 B-slave
8.2.4.7 Set List of Projected Slaves (SET_LPS and SET_LPS_R6 (6Bh))
The command SET_LPS_R6 (6Bh) differs from the command SET-LPs in:
• no empty byte (3)
• half so long LPS list
With the bit 2
5
is selected if the upper (=1) or lower (=0) part of the LCS is read.
With this call, the list of configured AS-i slaves is transferred for permanent storage
in the EEPROM of the master.
When this command is executed, the AS-i master changes to the offline phase and
then changes back to the normal mode (warm restart).
This command can only be executed in the configuration mode.
Request
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 26
16
2 T – circuit
3 – B slave address
Response
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 26
16
2 T result
3 xID2 xID1
4 ID I0
Response
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 29
16
2 T result
