The coding of requests for commands to reading and writing is following therefore:
8.1.1 List of all Commands
Request
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 command
2 T 0 circuit
3 Request parameter byte 1
… …
Values for command
command value meaning
Req
Len
Res
Len
RD_7X_IN 50
16
Read 1 7.3-slave in.data 3 10
WR_7X_OUT 51
16
Write 1 7.3-slave out.data 11 2
RD_7X_OUT 52
16
Read 1 7.3-slave out.data 3 10
RD_7X_IN_X 53
16
Read 4 7.3-slaves in.data 3 34
WR_7X_OUT_X 54
16
Write 4 7.3-slaves out.data 35 2
RD_7X_OUT_X 55
16
Read 4 7.3-slaves out.data 3 34
WR_74_PARAM 5A
16
Write S-7.4/S-7.5-slave parameter ≥6 2
RD_74_PARAM 5B
16
Read S-7.4/S-7.5-slave parameter 4 ≥3
RD_74_ID 5C
16
Read S-7.4/S-7.5-slave ID string 4 ≥3
RD_74_DIAG 5D
16
Read S-7.4/S-7.5-slave diagnosis
string
4 ≥3
GET_LISTS 30
16
Get LDS, LAS, LPS, Flags 2 29
GET_FLAGS 47
16
Get_Flags 2 5
GET_DELTA 57
16
Get list of config. diff. 2 10
GET_LCS 60
16
Get LCS 2 10
GET_LAS 45
16
Get_LAS 2 10
GET_LDS 46
16
Get_LDS 2 10
GET_LPF 3E
16
Get_LPF 2 10
GET_LOS 61
16
GET_LOS 2 10
SET_LOS 62
16
SET_LOS 10 2
GET_TECA 63
16
Get transm.err.counters 2 34
GET_TECB 64
16
Get transm.err.counters 2 34
GET_TEC_X 66
16
Get transm.err.counters 4 ≥3
READ_FAULT_DETECTOR 10
16
Read Fault Detector 2 4
SET_OP_MODE 0C
16
Set_Operation_Mode 3 2
STORE_CDI 07
16
Store_Actual_Configuration 2 2
READ_CDI 28
16
Read_Actual_Configuration 3 4
SET_PCD 25
16
Set_Permanent_Config 5 2
