AS-Interface
Command Interface
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group · Tel.: Germany (6 21) 7 76-0 · USA (3 30) 4 25 35 55 · Singapore 7 79 90 91 · Internet http://www.pepperl-fuchs.com
Issue date - 21.12.2005
46
8.2.2.12 Get transm.err.counters (GET_TEC_X)
Beginning with a definite slave address, the counts of the n error counters are be-
ing read out with this call.
With every reading out the counts, the error counters will be restarted.
The counts are being read out via the correspondending host interface and will be
deleted with every read access. The counter´s value is limited to 254. 255 will
cause a counter overflow.
The counts could be independent of the counters, which are displayed in the dis-
play of the gateway.
8.2.2.13 Functional profiles
Further diagnosis functions for "Safety at Work" and for availability vice versa for
warnings of integrated sensors are explained detailed in the chapter "
Functional
profiles" (chapter 8.2.3).
Response
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 64
16
2 T result
3 APF
4 slave 1B
… …
34 slave 31B
Request
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 66
16
2 T – circuit
3 1. slave address
4 number of counters
Response
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 66
16
2 T result
3 counter 1
… …
n counter n - 2
