Meaning of bit operation mode:
0 = protected mode
1 = configuration mode
8.2.4.3 Store Actual Configuration (STORE_CDI)
With this call, the (actual) configuration data (I/O configuration, ID code, extended
ID1 code and extended ID2 code) of all AS-i slaves are stored permanently in the
EEPROM as the (expected) configuration data. The list of activated AS-i slaves
(LAS) is adopted in the list of permanent AS-i slaves (LPS).
When this command is executed, the AS-i master changes to the offline phase and
then changes back to the normal mode (warm restart on the AS-i master).
This command can only be executed in the configuration mode.
8.2.4.4 Read Actual Configuration (READ_CDI)
With this call, the following configuration data of an addressed AS-i slave obtained
by the AS-i master on the AS-Interface are read.
• I/O configuration
• ID code
• Extended ID1 code
• Extended ID2 code
The configuration data are specified by the manufacturer of the AS-i slave.
Request
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 0C
16
2 T – circuit
3 operation mode
Response
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 0C
16
2 T result
Response
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 07
16
2 T result
Request
byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 28
16
2 T – circuit
3 – B slave address
