8.2.5.16 Write Flag
Use this command to write the flag of a control program.
The control program of devices with control functions accept data from the PB in-
terface.
8.2.5.17 Read Flag
Use this command to read out the flags of a control program.
The control program of devices with control functions accept data from the inter-
face
Request
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 0x85
2 T – circuit
3 introductory address
4 number n
5 number 1
... ...
n number n
Response
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 0x85
2 T result
Request
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 0x86
2 T – circuit
3 introductory address
4 number n
Response
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 0x86
2 T result
3 data 1
...
n data n
