Pepperl+Fuchs VBG-PB-K25 - Codes Indicated by Basic Master

AS-i/PROFIBUS Gateway
Appendix
Subject to reasonable modifications due to technical advances. Copyright Pepperl+Fuchs, Printed in Germany
Pepperl+Fuchs Group · Tel.: Germany (6 21) 7 76-0 · USA (3 30) 4 25 35 55 · Singapore 7 79 90 91 · Internet http://www.pepperl-fuchs.com
Issue date - 21.12.2005
95
10.2 Codes indicated by basic master
The basic master cannot display the following messages in a numeric form:
94 Error while changing the slave address in protected operating mode: Slave
has wrong configuration data.
95 Error while changing slave address in protected operating mode: The con-
figuration error was caused by a superfluous slave (instead of a missing
slave).
APF Offline because of Power Fail
LOS Offline because of LOS
OFH Offline because of Host
OFL Offline - other cause
SEA Collet phase
(Current lignht) error-free function
EFL Ground fault
...
