8.2.3.8 Replacement of Safety Slaves Input Data
Function 0F
16
Use this function to replace safety slaves input data with "interpretation data". If
the function is active, so have safety slaves input data the following meaning:
Bit 0,1: 00=channel 1 has released 11=channel 1 has not released.
Bit 2,3: 00=channel 2 has released, 11=channel 2 has not released.
Set:
Read:
Response
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 7E
16
2 T result
3
change buffer
1
1. Value: 0=change buffer off, 1=change buffer on)
This command replaces the old command MB_FP_LSS_ENABLE
Request
Byte
2
7
2
6
2
5
2
4
2
3
2
2
2
1
2
0
1 7D
16
2 T – circuit
3 0F
16
4
safety slaves
1
1. Value: 0= no substitute value, 1=substitute value for safety slaves
