The master is now in configuration mode.
Result: See chapter 8.1.2 "Values for Results".
2. Write single configuration to master
Writing a configuration of an AS-i slave to the master.
For example:
16-bit input 4 CH at address 4 (Slave datasheet)
ID: 3
hex
ID2: E
hex
IO: 7
hex
ID1: F
hex
No result because toggle bit = 0.
Response
Byte 1 0C
hex
Byte 2 80
hex
(T = 1, result = 0)
Byte 3 00
hex
(or old values)
Byte 4 00
hex
(or old values)
… …
Byte 12 00
hex
(or old values)
Request: SET_PCD
Byte 1 25
hex
(SET_PCD)
Byte 2 00
hex
(T = 0, master 1, single master)
Byte 3 04
hex
(slave address to write to master)
Byte 4 EF
hex
(ID + IO to configurate)
Byte 5 37
hex
(xID2 + xID1 to configurate)
Byte 6 00
hex
… …
Byte 12 00
hex
Response
Byte 1 00
hex
(or old values)
Byte 2 00
hex
(or old values)
Byte 3 00
hex
(or old values)
Byte 4 00
hex
(or old values)
… …
Byte 12 00
hex
(or old values)
