36 . Spectrum 100 Series User’s Guide
Icon Description Connector
Type
Voltages Maximum
Currents
Keyboard. Connects a keyboard or
barcode reader to the spectrometer.
Mini-DIN
6-way
+5 V 0.65 A
+12 V < 100 mA
Serial port. Connects a PC to the
instrument using an RS232 interface
cable. This connector is only used for
service diagnostics.
9-way
D-type
- 12 V < 100 mA
Universal serial bus (USB). This
connector is not used.
USB < 5 V < 100 mA
10 Base-T Ethernet connector. This is
the standard interface between the PC
and the instrument, or between a
Local Area Network (LAN) and the
instrument. If connecting directly
from the PC to the instrument use the
Category 5 UTP Cross-Over cable
supplied. If you are connecting to
your network, use a standard
Ethernet cable.
DO NOT USE THE CROSS-OVER
CABLE TO CONNECT TO YOUR
NETWORK.
Ethernet < 5 V < 100 mA
+ 5 V < 100 mA
A.U.I.
Attachment Unit Interface. Can be
used to connect the instrument to a
LAN.
11-way
mixed
D-type
± 12 V
50 mA
+12 V 0.65 A
-12 V 0.65 A
EXT. R
Right external detector module.
Connects to an external detector
module. Usually the detector is placed
in an accessory placed on the right of
the instrument.
High
density
D: 15 way
+ 5 V 4 A
+12 V 0.65 A
-12 V 0.65 A
Microscope external detector module.
Connects to a PerkinElmer infrared
microscope, placed on the left of the
instrument.
High
density
D: 15 way
+5 V 4 A
