Other connectors
The communications ports for peripheral devices are illustrated in Figure 10.
Figure 10 Communications ports
Icons which identify the function of each of the communications ports are printed on the
hinge molding directly above the communications port.
Sample area purge
Instrument pur
g
e
|0|0
A.U.I.
EXT.R
