Advanced Maintenance . 87
Replacing the Source
WARNING
Switch off the mains power supply to the spectrometer, wait 60
seconds and disconnect the power cable before you open the cover of
the spectrometer. This makes sure that you are safe from electrical
shock and laser radiation.
WARNING
Due to its high operating temperature allow sufficient time for the
source to cool before attempting to remove it.
1. Open the main cover of the instrument as detailed on page 84 and identify the
Source (Figure 34).
Figure 34 Source location
Caution, hot surface.
The source housing and source itself will be hot if recently switched on.
Allow to cool before performing the following procedure.
CAUTION
The source element is brittle and can be broken if not handled
properly. Be careful when removing and installing the source.
Do not touch the glass bulb as this will degrade the performance of the
bulb and shorten its life.
Source Source
