Pfaff 421E1 - Page 61

Programming
11 - 24
Fig. 11 - 43
1 2
3
4 5 6 7 9 0
Enter
8
Esc
Clear
● Program the second seam section:
In this seam section the
- stitch length should be 5.0 mm
- and a stitch count should be carried out (1 stitch).
# 2
NO. OF STITCHES 0
● Select the stitch length function.
1 2
3
4 5 6 7 9 0
Enter
8
Esc
Clear
Fig. 11 - 42
ROLLER PRESSER: 3.5 MM FEED WHEEL: 3.5 MM
[ VALID: 0.8 MM - 5.0 MM DIFF.: 1 MM ]
● Input the value for the stitch lengths.
● Confirm the entry with the Enter key.
# 2
NO. OF STITCHES 0
● Select the seam section end function (number key 9).
● Select the menu for inputting the number of stitches (number key 1).
Display Fig. 11 - 45 appears.
Enter
0
5
# 2
NO. OF STITCHES 0
Fig. 11 - 41
1 2
3
4 5 6 7 9 0
Enter
8
Esc
Clear
Fig. 11 - 44
1 2
3
4 5 6 7 9 0
Enter
8
Esc
Clear
