PG DRIVES TECHNOLOGY AC TRACTION – TECHNICAL SPECIFICATIONS
1 Electrical
1.1 Voltage Specifications
Model Voltage Nominal Battery Voltage Absolute Operating Voltage Range
ACT2xxX 24V Units 24V 14.5 – 34.0V
ACT4xxX 48V Units 24-48V 14.5 – 61.0V
ACT8xxX 80V Units 72-80V 43.0 – 98.0V
1.2 Current Specifications
Model Voltage Maximum Current (rms) / Time Continuous Current (rms) – 1 Hour
ACT225S 24V 180A / 60s 80A
ACT425S 48V 180A / 20s 80A
ACT445M 48V 320A / 60s 180A
ACT465L 48V 460A / 60s 260A
ACT817S 80V 120A / 20s 70A
ACT835M 80V 250A / 60s 120A
ACT865L 80V 460A / 60s 240A
Switching Frequency: Controller frequency is 8KHz.
Motor frequency is 16KHz.
Electrical Isolation: Enclosure to any live part = 1KV. Controller internal insulation specified at >10MΩ @500V DC.
2 Environmental
Ingress Protection (IP): The enclosure is protected to IP54 (varnished PCB).
Vibration: 6G, 40-200Hz for 1 hour, in x, y and z planes.
Operating Temperature: -30
o
C to +40
o
C ambient around controller.
Storage Temperature: -40
o
C to +70
o
C.
Humidity: 95% maximum, non-condensing.
SK79646-01 93
