E. Clutch driven pulley
1.Dismantle the clutch
a. Remove left crankcase cover.
b. Remove driving plate.
c. Remove driving belt.
d. Remove the M10 locking nut, then the clutch.
2.Assembling the clutch: please follow the opposite procedure of dismantling.
3.Checking the clutch:
a. Check the clutch driven face.
Check the clutch cover about its wearing
Condition and inner diameter measurement.
b. Check the clutch lining wearing condition
and measure the lining thickness
limit of use:change it below 2.5mm.
Locking torque:
M10: 3.5~4.0kg-m
Dismantling the clutch needs the special
Tool. please contact your dealers.
Limit of use:
50cc:Change it when above 117.5mm
