Philips BDL3245E/00 - Page 40

40
Remark: Parts position can be searched by using FIND function in PDF.
BNC_G_Y 7
BNC_B_Pb 7
BNC_R_Pr 7
C536
NC
C537
NC
C538
NC
R195
75R 1/10W 1%
R196
75R 1/10W 1%
R197
75R 1/10W 1%
COMP_Dect9
C550
5PF 50V
R775 5K1 1/16W 5%
R776
10K 1/16W 5%
R126 0R05 1/16W
R152 0R05 1/16W
C546 22uF 16V
R160 0R05 1/16W
+5V 2,3,6,9,10,15
+5V
C503
100N 16V
1 3 5 2 4 6
7 8 9 10 11 12
CN406
BNC
C186
5PF 50V
C185
5PF 50V
C553
5PF 50V
R760
1K 1/16W 5%
C184
5PF 50V
R765
270K 1/10W 5%
R759
1K 1/16W 5%
D128
LL4148
BNC_G_Y
BNC_G_Y
BNC_R_Pr
1 2
FB109
60 OHM
1 2
FB105
60 OHM
1 2
FB107
60 OHM
FB197
300OHM
YPbPr IN
G/Y
C545
100N 16V
I/O1
1
GND
2
I/O2
3
I/O3
4
VDD
5
I/O4
6
U119
AOZ8105CI
1OUT
1
1IN-
2
1IN+
3
GND
4
2IN+
5
2IN-
6
2OUT
7
VCC+
8
U120
AS358MTR-E1
+5V_SYNC_DEC
B/Pb
20101217
component side
R/Pr
BNC_B_Pb
