6
Controls (See fig. 1 & 2.
Features are same on both
Center
&
Station
unless stated
)
Top & Front
STANDBY ON - press briefly for standby on/ off (green light indicator when streaming)
-press and hold to activate ECO POWER standby (red light)
EJECT –eject disc (
on
Center
only)
ACTIVE – indicator lights up during wi-fi streaming (broadcast from Station)
LIKE ARTIST - selects all tracks of a specified artist
LIKE GENRE - selects all tracks of a specified genre
MATCH GENRE – activates preset sound setting to match a genre
MENU - menu view on/ off
MUSIC FOLLOWS ME - stream music from Center to (other) Station(s)
MUSIC BROADCAST – activates music broadcast at a chosen Station
(
on
Center
only
)
DBB – toggles Dynamic Bass Boost options to enhance bass
VIEW – display view options
Flat Plexi-Piston™ speakers
IR
–infrared sensor for remote controls
Always point the remote control towards these sensors
SOURCE – toggles 4 sound sources
REC – to record from a selected source. Lights up red when recording
(
on
Center
only)
INCR.SURROUND – Incredible Surround sound option on/off
MUTE – mute sound on/off
Navigation control:
OK start /pause playback; confirm a setting;
/
previous/ next level screen;
Up / previous / scroll upwards/ fast search play backwards
Down / next / scroll downwards/ fast search play forwards
STOP – stops CD/ HD playback;
- stops music broadcast;
- stops recording; (
on
Center
only)
MARK/ UNMARK - mark or unmark tracks for ripping (
on
Center
only)
VOL -/+ - adjusts volume
Left/ Right/ Rear…
X – socket for 3.5mm headphones (not included)
WI-FI - antenna
screw holes – for wall mounting
FM tuner coaxial cable connection (cable not included)
LAN/ Ethernet connection
AUX IN Left, Right – connect to the analogue audio output of external devices
LINE OUT Left, Right – connect to the analogue audio inputs of an external recording device/
amplifier (
on
Center
only
)
FM ANTENNA - connect the supplied FM cable here
Voltage selector –
some versions only. [Korea/ 01 version]
