1.1.3 Status and diagnostic indicators
1.1.4 Firmware versions and their functions
1.1.4.1 For the following switch versions (LM)
– FL SWITCH LM 8TX
– FL SWITCH LM 4TX/2FX
– FL SWITCH LM 4TX/2FX SM
Firmware Version 1.04 provides the standard switch functions.
Firmware 2.02 offers the following additional functions:
– Multicast filter mechanisms
– IGMP snooping and querier function
– Port mirroring
– Port statistics
– Link status via alarm contact
– MAC address clearing
Firmware 2.02 offers the following additional functions:
– Optimized IGMP function, query port is not entered in GDA
– Optimized Rapid Spanning Tree Protocol (RSTP), RSTP function optimized in
connection with glass fiber FX port.
Des. Color Status Meaning
US1 Green ON Supply voltage US1 in the tolerance range
OFF Supply voltage US1 less than 18 V DC
US2 Green ON Supply voltage US2 in the tolerance range
OFF Supply voltage US2 less than 18 V DC
LNK Green ON Link active
OFF Link inactive
Flashing Transmitting/receiving
100 Yellow ON Full duplex mode
OFF Half duplex mode
Flashing Collision detected
