Configuration and diagnostics
7278_en_04 PHOENIX CONTACT 3-49
3.4.2 User interface functions
3.4.2.1 Functions during the boot process after a restart
If you open the user interface in the first five seconds directly after an LMS restart, you have
the option of triggering a firmware update. Since the actual switch firmware is not yet started
at this stage, even in the event of an error, e.g., if the firmware on the device is faulty, this
firmware can still be updated (see "Starting with faulty software" on page 3-52).
3.4.2.2 Functions during operation
The following functions are available in the user interface:
– Setting IP parameters
– Selecting the addressing mechanism
– Resetting to default settings
– Activating/deactivating the web server, Rapid Spanning Tree, and the SNMP interface.
3.4.2.3 Structure of the user interface screens
Login Screen
Figure 3-29 User interface login screen
The login screen indicates the version of the firmware used. A password must be entered to
make other settings. By default upon delivery, the password is "private". It is case-sensitive.
We strongly recommend that you change the password (via SNMP or WBM).
The activation/deactivation of the web server only takes effect after a "SAVE" and
subsequent restart.
All settings are transferred using "APPLY", but are not saved permanently. Use the
"SAVE" function to save the active configuration settings permanently.
Login Screen
--->Phoenix Contact Lean Managed Switch <---
Phoenix Contact GmbH & Co. KG
www.phoenixcontact.com
Running switch application version: x.xx
Password: [ ]
