Startup and functions
7278_en_04 PHOENIX CONTACT 2-1
2Startup and functions
2.1 Basic settings
2.1.1 Default upon delivery/default settings
By default upon delivery or after the system is reset to the default settings, the following
functions and properties are available:
– The password is "private".
– All IP parameters are deleted. The switch has no valid IP parameters:
IP address: 0.0.0.0
Subnet mask: 0.0.0.0
Gateway: 0.0.0.0
– BootP is activated as the addressing mechanism.
– All available ports are activated with the following parameters:
- Auto negotiation and auto crossing for RJ45 ports.
- 100 Mbps - full duplex for FX ports.
– All information collected by the SNMP agent is deleted.
– The web server, SNMP agent, and V.24 (RS-232) interface are active.
– The "Rapid Spanning Tree" WBM configuration page is activated.
– The alarm contact only opens in the event of non-redundant power supply.
– The aging time is set to 48 seconds.
2.1.2 Assigning IP parameters
When the supply voltage is switched on, the switch sends requests (BootP requests) to
assign IP parameters.
The assignment of valid IP parameters is vital to the management function of the switch.
Options for assigning IP parameters:
– Configuration via the BootP protocol (default upon delivery)
– Static configuration via the management interfaces
NOTE: The IGMP snooping function is activated by default upon delivery for "E" versions.
For other versions, it can be activated as necessary in WBM.
The basic Ethernet functions do not have to be configured and are available when the
supply voltage is switched on.
The "BootP" function can be deactivated via the management. By default upon delivery,
the "BootP" function is activated.
