4.2.4 Example topologies
4.2.4.1 Redundant coupling of network segments
In this example, two network segments are connected via redundant data paths. Two STP
components have ports in the "Blocking" state (highlighted in gray). This is sufficient to
operate the network.
Figure 4-11 Redundant coupling of network segments
