3.2.3.3 General Configuration
"IP Configuration" menu
This page displays the set IP parameters and addressing mechanism. To change the IP
parameters via WBM, "Static" assignment must be selected.
Figure 3-8 "IP Configuration" web page
"SNMP Configuration" menu
System Information This part of the table is used to display or modify user-specific device data, e.g., location,
device name or function.
Figure 3-9 "SNMP Configuration" web page
If you modify the IP address and/or the other IP parameters via WBM, once you click on
"Apply" you will no longer have access via the IP address set in the browser.
