FL SWITCH LM ...
3-10
PHOENIX CONTACT 7278_en_04
• Enter the device password (default: "private") and click on "Apply".
Figure 3-12 Web interface with the update parameters
The following window appears after a few moments.
Figure 3-13 Message following successful update
• Close and restart WBM.
Firmware update can take several minutes. You can monitor the download in the Factory
Manager message window (25%, 50%, 75%, 100%). Always wait until all the LEDs light
up after approximately two minutes and the device is available again after booting.
It is not ensured that all existing configuration data will be retained after a firmware
update/downgrade. Therefore, please check the configuration settings or return the
device to the settings default upon delivery.
NOTE: A voltage failure during a firmware update results in the destruction of the firmware
on the LMS. An update via XMODEM is required, see "Starting with faulty software" on
page 3-52.
