Keypad
Figure 4: Keypad
The keypad allows menu-driven operation of the LCD via the
arrow keys.
5241A003
INTERBUS
Diagnostics display
Keypad
Up Arrow
Down Arrow
Right Arrow, selection from
menu items or addresses
Left Arrow, selection from
menu items or addresses
ENTER, confirm selection
ESCAPE, leave menu item, change to
the next higher level
