30
5277A
Figure 24: DEBUG function
QFLG Menu Item (Quality Flag)
QFLG is displayed when exceeding a determined ratio of cy-
cles with/without errors.
Display reading:
- Line 1 - QFLG (Quality Flag)
- Line 3 - State of the quality bit in the diagnostic status reg-
ister.
Bit is set: ON
Bit is not set: OFF
5241A019
MODE
DIAG
DEBUG
Position
ID
Stopping cycles
Starting cycles
Position
ID
CODECODE
MPM QFLG
