34
5277A
The last device which has indicated an error is assigned to
number 1 of the list. If there are more messages than ten, the
oldest message will be removed. Press the arrow keys to se-
lect a message and the ENTER key to obtain information on
the peripheral fault:
- Line 2 - Device number
- Line 3 - Error code in HEX format. The corresponding
CODE element is displayed.
CRC TEN Menu Item
This menu allows the transmission quality of the bus to be
evaluated rapidly.
Display reading:
- Line 1 - CRC
- Line 2 - TEN
- Line 3 - List number (1 - 10). The list numbers are acces-
sible via the Right Arrow or Left Arrow keys. The device
characterized by the greatest number of transmission er-
rors is assigned to number 1. If you keep pressing the EN-
TER key at the selected entry number, the following
display can be read:
Line 1 - Error counter is flashing.
- Line 2 - Device number
- Line 3 - Error code in HEX format. The corresponding
CODE element is displayed.
