SCAN TIME Menu Item
The interval between two data cycles (cycle time) is dis-
played.
The cycle time can either be set by yourself or determined au-
tomatically by the controller board.
The display is updated every five seconds.
Display reading:
- Line 1 - SCAN
- Line 2 - TIME
- Line 3 - Indicates the update time in milliseconds.
OPTI TIME Menu Item
Display reading:
- Line 1 - OPTI
- Line 2 - TIME
- Line 3 - Indicates the optimum update time for bus oper-
ation in milliseconds.
FW-V Menu Item
Display of the firmware version.
Display reading:
- Line 1 - FW-V
- Line 2 - (empty)
- Line 3 - Displays the firmware version, e.g. 4.0.
HW-V Menu Item
Display of the hardware version.
Display reading:
- Line 1 - HW-V
- Line 2 - (empty)
- Line 3 - Displays the hardware version.
