The following diagram illustrates the process image monitor
of the IBS S5 DSC controller board for Siemens SIMATIC
®
S5 PLCs.
Siemens S5
Siemens S5 PLCs have four defined address areas:
P-area for IN data - Address area 0x1000 - 0x10FF
P-area for OUT data - Address area 0x0000 - 0x00FF
Q-area for IN data - Address area 0x1100 - 0x11FF
Q-area for OUT data - Address area 0x0100 - 0x01FF
In addition, there are four other address areas:
X-area for IN data - Address area 0x1200 - 0x12FF
X-area for OUT data - Address area 0x0200 - 0x02FF
Y-area for IN data - Address area 0x1300 - 0x13FF
Y-area for OUT data - Address area 0x0300 - 0x03FF
