length with which ID cycles are currently run.
Line 3 displays the contents of the IPMS error register. If the
state of the controller board changes during the time in which
the DEBG menu item is active, cycles are stopped and NOT
NOW is indicated, if required.
There is one fundamental difference between this menu and
other. The background color is independent of basic diagnos-
tics, it depends on this menu only.
As soon as a bus error occurs when starting up the bus device
after device or running cycles, the background color changes
from green to red. If the error has been eliminated, the back-
ground color changes back to green. This menu can only be
executed in the READY state. Thus, there are no conflicts
with basic diagnostics.
ADBG Menu ITEM (Auto Debug)
Help for Startup
This menu item has the same function as DEBG except for
the fact that functions are carried out automatically.
After selecting this menu item, the aim is to start up the bus.
When carrying out the step-by-step startup without errors,
data and ID cycles start after a waiting time of 1 second.
The diagnostic LEDs of the device allow to determine to what
extent the bus is started up. If all BA-LEDs are active, the bus
runs without errors.
As soon as a bus error occurs, it is attempted to restart the
bus after a waiting time of 1 second. This is repeated as long
as the step-by-step startup is carried out successfully.
Also, a new startup is attempted when the error counter is
greater than 10. The display reading corresponds to that of
the DEBG menu item.
