33
5277A
REC Menu Item
Display reading:
- Line 1 - REC
- Line 2 - Device number
- Line 3 - Error counter
PF Menu Item (Peripheral Fault)
Display reading:
- Line 1 - PF
- Line 2 - Device number
- Line 3 - Error counter
CRC Menu Item
Display reading:
- Line 1 - CRC
- Line 2 - Device number
- Line 3 - Error counter
In the menu items REC, PF and CRC, the devices represent-
ed in the second line can be selected via the arrow keys.
Right Arrow means the next device, Down Arrow the next bus
segment, Up Arrow one segment back and Left Arrow one de-
vice back.
PF TEN Menu Item
Display reading:
- Line 1 - PF
- Line 2 - TEN
- Line 3 - Shows a chronological list of the last ten devices
in which peripheral faults occurred.
The second and third line display NO CFG if no current con-
figuration frame is available.
