Fuse Types for INTERBUS Devices
All IBS devices with a 24V terminal are provided with TR5 fus-
es. They protect the device on the bus side and, if devices
with active inputs are used, on the input side. The TR5 fuses
are available from Phoenix Contact. The following table lists
the fuses which are used in the modules. Fuses which are sol-
dered in and can only be replaced at Phoenix Contact are list-
ed as well.
Table 1: Overview of fuse types
Module Device Fuse Type
Order No. Designation
Order No.
IBS CT
2750497 IBS CT 24 DIO 24/16-LK
SI. TR3 2AF
SI. TR3 5AF
2722645
2721976
IBS TR3 2AF
IBS TR3 5AF
2750507 IBS CT 24 DIO 24/16-T
SI. TR3 2AF
SI. TR3 5AF
2722645
2721976
IBS TR3 2AF
IBS TR3 5AF
2722182 IBS CT 24 DIO 16/8-LK
SI. TR3 2AF
SI. TR3 5AF
2722645
2721976
IBS TR3 2AF
IBS TR3 5AF
2722179 IBS CT 24 DIO 16/8-T
SI. TR3 2AF
SI. TR3 5AF
2722645
2721976
IBS TR3 2AF
IBS TR3 5AF
IB ST
2754309 IB ST 24 AI 4/SF SI. TR5 0,200AT 2753452 IBS TR5 0,2AT
2754309 IB ST 24 AI 4/SF SI. TR5 0,400AT 2753478 IBS TR5 0,4AT
2752534 IB ST 24 AI 4/SF-WT SI. TR5 0,400AT 2753478 IBS TR5 0,4AT
2752521 IB ST 24 AO 4/BP SI. TR5 0,400AT 2753478 IBS TR5 0,4AT
2754312 IB ST 24 AO 4/SF SI. TR5 0,400AT 2753478 IBS TR5 0,4AT
2752440 IBS ST 24-BK- DIO-8/8/3-T-WT SI. TR5 1AT 2806600 IBS TR5 1AT
2752440 IBS ST 24-BK- DIO-8/8/3-T-WT SI. TR5 5AT 2767383 IBS TR5 5AT
2753232 IBS ST 24 BK LB-T SI. TR5 1AT 2806600 IBS TR5 1AT
2752615 IBS ST 24 BK LB-T-WT SI. TR5 1AT 2806600 IBS TR5 1AT
2754435 IBS ST 24 BK-LK SI. TR5 1AT 2806600 IBS TR5 1AT
2753504 IBS ST 24 BK-RB-T SI. TR5 1AT 2806600 IBS TR5 1AT
2752411 IBS ST 24 BK DIO 8/8/3-T SI. TR5 1AT 2806600 IBS TR5 1AT
2751218 IBS ST 24 BK DIO 8/8/3-LK SI. TR5 1AT 2806600 IBS TR5 1AT
2721662 IBS ST 24 BK RB-LK DIO
8/8/3-LK
SI. TR5 1AT 2806600 IBS TR5 1AT
2754341 IBS ST 24 BK-T SI. TR5 1AT 2806600 IBS TR5 1AT
2752437 IBS ST 24 BK-T-WT SI. TR5 1AT 2806600 IBS TR5 1AT
2753012 IB ST 24 DI 32/2 SI. TR5 2AT 2752505 IBS TR5 2AT
2752479 IB ST 24 DI 32/2-WT SI. TR5 2AT 2752505 IBS TR5 2AT
2750808 IB ST 24 BDI 8/4 SI. TR5 0,4AT 2753478 IBS TR5 0,4 AT
2750170 IB ST 24 BDI 16/4 SI. TR5 1AT 2806600 IBS TR5 1AT
2721963 IB ST 24 BDI 32/4 SI. TR5 1AT 2806600 IBS TR5 1AT
2753708 IB ST 24 DIO 8/8/3-2A SI. TR5 4 AT 2753465 IBS TR5 4AF
2719166 IB ST 24 DIO 8/8/3-2A-WT SI. TR5 4AT 2750374 IBS TR5 4AT
2753449 IB ST 24 DIO 8/8/3-2A-S SI. TR5 4AT 2753465 IBS TR5 4AF
2751849 IB ST 24 DIO 8/8/R/3 SI. TR5 0,4AT 2753478 IBS TR5 0,4 AT
2719629 IB ST 24 AI 4/I SI. TR5 0,4AT 2753478 IBS TR5 0,4 AT
2751564 IB ST 24 AI 4/BP
SI. TR5 0,2AT 2753452 IBS TR5 0,2 AT
SI. TR5 0,4 AT 2753478 IBS TR5 0,4 AT
2750565 IB ST 24 AI 4/SF4
SI. TR5 0,2AT 2753452 IBS TR5 0,2 AT
SI. TR5 0,4AT 2753478 IBS TR5 0,4 AT
For some modules (printed in bold), the installed
medium-blow fuses are to be replaced by the ones
listed below after they have blown.
