The currently selected menu item is always displayed in the
first line. If another level is available under this menu item,
one of the respective menu items will flash in the second line.
If no further submenus are available, the second line displays
information specific to the currently selected menu item.
CFG Menu Item
The CFG menu item comprises the following subitems:
ID - Identification Code of the Selected Device
ID is displayed in line 1, the device number is flashing in line
2, and the ID code of the device is shown in line 3 (decimal
representation).
LEN - Process Data Length of the Device
LEN is displayed in line 1, the device number is flashing in line
2, and the process data length of the device in bit is shown in
line 3 (decimal representation).
LEVL - Bus Level of the Selected Device
LEVL is displayed in line 1, the device number is flashing in
line 2, and the device level is shown in line 3 (decimal repre-
sentation).
SWTC - List of Switched Off Devices
Here, a list of disconnected devices is displayed. According to
the physical bus configuration, the device which was first dis-
connected is assigned to the number 1 of the list. The list
numbers can be selected via the Left Arrow/Right Arrow keys.
The respective device number is displayed. Starting at list
number 1, the number of switched off devices can be dis-
played by pressing the Up Arrow key. The second line dis-
plays CNT (Count), line 3 the number of switched off devices.
NO CFG is displayed as long as there is no configuration. NO
DEV appears if none of the devices is switched off.
BRDG - List of Bridged Devices
Display and operation correspond to the SWTC menu item.
