5
5277A
- OUT1: Error at the outgoing interface
- OUT2: Error at the branching interface
- DEV: Error on a device
- USER: User error
- PF: Peripheral fault
MODE
If the MODE menu item is active, further menu items can be
selected from this point.
- CFG Configuration
- DIAG Diagnostics
- STAT Statistics
- OPT Other display modes
MONI
Indicates that the "monitor" mode is activated, e.g.
S5 = host monitor for the S5 controller board.
HEX
The displayed value in the main line is a hex number. If the
HEX segment is not activated, the value is represented as
decimal number.
Line 2
Main line:
Four and a half alphanumeric positions for variable displays.
PARA
The displayed value is the parameter of a message.
CODE
The displayed value represents a code.
SEG.POS
The displayed value is a device number (bus segment and lo-
cation). You will find an example of the counting method on
the inside cover page of this guide.
HEX
The displayed value in the second main line is a hex number.
If the HEX segment is not activated, the value is represented
as a decimal number.
2
