18 19
4.2 Lanyard 4.3 Pouch
4.4 Audio cable
4.5 Recording cable
This is used to wear the microphone around the neck.
• Distance from mouth to top of microphone should
be approximately 20 cm / 8 inches.
• Lanyard features a safety breakaway for urgent removal.
The lanyard clips into the top of the microphone.
Use this to protect the
microphone from scratches.
Hand wash only.
Used to connect an external
audio device.
Note: Both mono and stereo
plugs can be used. When using
stereo plugs, the stereo audio
signal will be transformed into
a mono signal.
Used to record the microphone’s
output signal on a computer,
tablet, or other recording device
(see section 9.2.2).
20 cm
8 inches
