PIAGGIO X9 Evolution 125 2008 - Page 104

Removing the wheel axle bearings
- Take out the clip on the outside of the gearbox
cover.
- Support the hub cover and expel the bearing.
By means of the appropriate tools, remove the oil
guard as in the figure.
Specific tooling
020376Y Adaptor handle
020477Y Adaptor 37 mm
020483Y 30 mm guide
020359Y 42x47-mm Adaptor
020489Y Hub cover support stud bolt set
Engine X9 Evolution 125
ENG - 104
