-Remove diffuser.
- Remove the sprayer.
N.B.
WHEN CLEANING THE CARBURETTOR BODY REMOVE
THE SPRAYER TO AVOID LOSING PARTS. IF THE SPRAY-
ER IS FORCED IN ITS HOUSING DO NOT ATTEMPT TO
REMOVE IT AS THIS WILL ONLY DAMAGE IT.
-Remove the minimum nozzle.
