8. Main fuses
10. Battery
11. Starter motor
12. Relay for start-up
13. Secondary fuses
14. Stop button on rear brake
15. Stop button on front brake
16. Start-up button
27. Rear stop light
49. Key switch
50. Side stand button
Level indicators and enable signals section
KEY
1. Electronic ignition device
2. Immobilizer aerial
4. Relay for disabling start-up
5.Relay engine stop
7. Engine stop switch
8. Main fuses
X9 Evolution 125 Electrical system
ELE SYS - 63
