10. Battery
13. Secondary fuses
35. Oil pressure sensor
38.Wheel turning sensor
39. Fuel level transmitter
40. Thermistor
41. Digital instrument panel
A. Preset warning light
B. ABS wiring warning light
C. Stop light bulb burned warning light
D. Disabled engine warning light
E. Oil warning light
F. Low fuel warning light
G. Headlight warning light
H. High-beam warning light
I. Left turn indicator warning light
L. Emergency flashing warning light
M. Right turn indicator warning light
42. Analogue instrument panel
A. Immobilizer warning light
46. External temperature sensor
49. Key switch
50. Side stand button
Electrical system X9 Evolution 125
ELE SYS - 64
