The X9 model has an instrument panel subdivided into 2 sections: the analogue section fastened to the windshield, and the
digital section integral to the handlebar.
The analogue section comprises:
- A speedometer with double scale (MPH/KMH) controlled by the tone wheel;
- An rpm indicator controlled by the signal coming from the HV coil.
- A fuel gauge controlled by a resistive sensor (inside the tank)
- A coolant temperature gauge controlled by a resistive sensor (on the head)
These instruments are electrically controlled by stepper motors.
The digital section provides the displays of:
A: Preset warning light *
B: Preset warning light *
C: Preset warning light *
D: Engine disabled
E: Oil pressure
F: Fuel reserve
G: Tail lights and low-beam lights: green
H: High-beam lights on
I: Left turn indicator
L: Emergency lights (four arrows)
M: Right turn indicator
* The DGT instrument does not have the preset warning light LED
Low fuel indicators, turn indicators and emergency flashing light are activated by the instrument electronic components. For
instance, the fuel reserve warning light bulb lights up only when the reserve signal coming from the tank persists for over 13.5
seconds. This prevents the reserve warning light from flickering.
- This flashing function has been incorporated to the instrument electronic components: that is, the emergency lights can work
with the switch set to "OFF" and the control switch deactivated. The control switch is active only when the instrument panel is
on.
To guarantee safety while riding, the "turn indicator control" function is connected to the odometer. In case you forget the signal
ON, it will turn off automatically after riding 1 kilometre.
- The "engine disabled" warning light is activated through the side stand switch and the emergency switch located on the
handlebar right side.
- The LCD display provides a 5-digit indication for the total distance covered by the vehicle. This can be expressed in kilometres
or miles: naturally such indication cannot be reset. To select the indication it is necessary to push simultaneously the
"Trip" and "M" buttons and then turn the key switch to "ON"; by holding these 2 buttons for another 3 seconds, the
word "SET" is displayed, and then the distance covered shifts from miles to kilometres or vice versa.
The instrument panel digital section has a liquid crystal display
and 4 control buttons.
Electrical system X9 Evolution 125
ELE SYS - 78
