Function description
Operating Manual PITreader, PITreader Firmware V1.5.x
1004806-EN-08
| 28
} Input Register (Word/16 Bits)
PITreader -> Modbus Client, register access read (with FC04)
Address Content
3x0001 … 3x0002 PITreader order number (coded)
Bits 31 to 24: Product group (00 = empty, 01 = G1)
Bits 23 to 20: Revision (00 = empty )
Bits 19 to 0: Product number
Examples:
PITreader base unit (402255): 0x 00 0 6234F
PIT gb RLLE y up ETH (G1000020):: 0x 01 0 00014
3x0003 ... 3x0004 PITreader serial number
3x0005 ... 3x0006 Operating hours counter in minutes
3x0007 ... 3x0008 RTC time stamp, seconds since 01.01.2000 00:00 (UTC)
3x0009
LED colour (see also LED control [ 26])
3x0010
LED flash mode (see also LED control [ 26])
3x0011 Diagnostic status (all diagnostic messages are assigned a severity;
severity 3 = error, severity 8 = warning, severity 13 = status inform-
ation)
3x0013 … 3x0016 PITreader order number (ASCII)
3x0017 PITreader revision (ASCII)
3x0019 SEU status information (see also operating manual
PIT m4SEU, section 5.5)
Default value if no SEU is connected: 0x00F0 (decimal: 240)
3x0025 … 3x0028 Security ID (data from the transponder key)
3x0029 … 3x0030 Reserved
3x0031 … 3x0032 Permission (code word)
3x0033 Permission (integer, 0 to 64)
3x0034 Authentication status (0 = not authenticated, 1 = transponder au-
thenticated successfully)
3x0035 … 3x0036 Order number (transponder key)
3x0037 … 3x0038 Serial number (transponder key) (see also Serial number of the
transponder key [ 21])
3x0039 Reserved
3x0040 Reserved
3x0059 … 3x0060 Group 0
3x0061 … 3x0062 Group 1
3x0063 … 3x0064 Group 2
3x0065 … 3x0066 Group 3
3x0067 … 3x0068 Group 4
3x0069 … 3x0070 Group 5
3x0071 … 3x0072 Group 6
3x0073 … 3x0074 Group 7
