Function description
Operating Manual PITreader, PITreader Firmware V1.5.x
1004806-EN-08
| 29
Address Content
3x0075 … 3x0076 Group 8
3x0077 … 3x0078 Group 9
3x0079 … 3x0080 Group 10
3x0081 … 3x0082 Group 11
3x0083 … 3x0084 Group 12
3x0085 … 3x0086 Group 13
3x0087 … 3x0088 Group 14
3x0089 … 3x0090 Group 15
3x0091 … 3x0092 Group 16
3x0093 … 3x0094 Group 17
3x0095 … 3x0096 Group 18
3x0097 … 3x0098 Group 19
3x0099 … 3x0100 Group 20
3x0101 … 3x0102 Group 21
3x0103 … 3x0104 Group 22
3x0105 … 3x0106 Group 23
3x0107 … 3x0108 Group 24
3x0109 … 3x0110 Group 25
3x0111 … 3x0112 Group 26
3x0113 … 3x0114 Group 27
3x0115 … 3x0116 Group 28
3x0117 … 3x0118 Group 29
3x0119 … 3x0120 Group 30
3x0121 …3x0122 Group 31
3x0159 … 3x0166 Check sum for basic coding
3x0167 … 3x0174 Check sum for OEM coding
3x1000 … 3x1519
User data (see also information below and User data [ 21])
INFORMATION
Values from the user data always start at register limits. With data that only
requires a data width of 1 Byte, the actual value is written in the low byte
and the high byte is filled with “0”.
The address of the Modbus/TCP Register is displayed in the web applica-
tion under Configuration -> User data. The address can also be calculated
using the following formula:
Address_n = Address_(n-1) + RoundUp_2-Byte ( Length_(n-1) )
