Functiondescription
OperatingManualPNOZs50
1002194EN02
22
4.2.7 Outputtest
Outputsthatareswitchedonarecheckedviaregularofftests.
}
Testpulsesforoutputsthatareswitchedon:seetechnicaldetails
}
Outputsthatareswitchedonareswitchedoffforthedurationofthetestpulse.
}
Theloadmustnotswitchoffbecauseofthetest.
}
Theswitchofftestscannotbeturnedoff.
Dualpoleoutputsthatareswitchedoffarecheckedviaregularontests.
}
Thetestpulsesswitchthepositivepoleoftheoutput.Theloadmustnotswitchonbe
causeofthetest.
Testingforshorts
}
Atestisregularlycarriedouttocheckforshortsbetweentheoutputs.
4.3 Statusdisplay,configurationandmessages
4.3.1 Overview
Theconfigurationissetusingthedevice'srotaryknobwithpushbuttonandisthendis
played.Accesstotheconfigurationmenuispasswordprotected.
Thefollowingdevicepropertiescanbeconfigured:
}
Supplyvoltagetothepowercircuits
}
Signalstotheoutputsofthepowercircuits:
– Overexcitationtime
– Reducedvoltage
}
Feedbackloop:
– Max.ventilationandapplicationtime
– Highorlowlogic(N/OorN/C)
– Evaluationoftestpulses
}
Offset(startvalue)forthenumberofoperations
Additionalinformationonthedisplay:
}
Statusdisplay
}
Numberofoperations
}
Statesofinputsandoutputs
}
Informationonthedevice
}
Softwareversions
}
Errormessages
INFORMATION
Furtherinformationontheconfigurationcanbefoundinthesectionentitled
"Commissioning",under"Displaymenuandconfiguration".
