Commissioning
OperatingManualPNOZs50
1002194EN02
31
6.1.6.2 Slowshutdown
Activationviasinglepoleout
puts
PLC:Safetycontrolsystem
S35
S36
O3
O4
PLC
PNOZ s50
Connecttheinputsto24VDC
ifslowshutdownisnotbeing
used.
S11:Voltageoutput24VDC
S35
S36
S11 24 V DC
6.1.7 Outputs
Statusoutputs
PLC:Safetycontrolsystem
I1
I2
O3
O4
PLC
PNOZ s50
I3
O5
6.1.8 Feedbackloop
Feedbackloop
AN/Ccontactisshowninthe
connectiondiagram.AN/O
contactcanalsobecon
figured.
S11 24 V DC
Y1
Y2
Feedbackloopwithtest
pulses
Pleasenotetheallocationof
thetestpulsesandfeedback
loops:
T0<>Y1
T1<>Y2
Y1
Y2
T0
T1
