Commissioning
OperatingManualPNOZs50
1002194EN02
39
off
450
1000
1500
2150
1
3
2
O1
T 1000 ms
U 12 V
Cancel Store
4
Fig.:Changingnumericvalues
6.2.5.3 Displaymenuatcoldstart
WhenthedeviceisswitchedoninthePowerOnoperatingstate(coldstart),thememory
contentsofthedeviceandthechipcardarereadandcompared.Ifthereareanydevi
ations,messageswillappear.
Overview Display Description
NoChipcarddetected
Nochipcardandnochip
cardholderinthedevice.
No Cipcard
detected
Proceed?
No Yes
NoInsertchipcardoronly
chipcardholder
Yes–SwitchtoRUNoperat
ingstate,withoutachipcard
inserted
ChipcardisDefect
Thechipcardisdefective
or
Onlythechipcardholderis
inserted.
Cipcard is
defect, remove
Or replace
Proceed
Proceed–1.Useavalid
chipcardorinsertchipcard
holderonly.2.Restart
devicewithProceed.
Memoriesareunequal
Theparametersonthechip
cardandinthedevice
memoryarenotidentical.
Memories are
unequal, Copy
Ext. To Int. ?
Int. To Ext. ?
Copy from
Ext. Memory
and Restart?
No Yes
Copy from
Int. Memory
and Restart?
No Yes
Memories are
unequal, Copy
Ext. To Int. ?
Int. To Ext. ?
Ext.ToInt.–Switchtothe
nextmenutodownload
parametersfromthechip
cardtothedevicememory
Int.ToExt.–Switchtothe
nextmenutouploadpara
metersfromthedevice
memorytothechipcard
