Commissioning
OperatingManualPNOZs50
1002194EN02
35
6.2.5 Displayandconfiguration
6.2.5.1 Menuoverview
Thefollowingdiagramsillustratetheprinciplestructureoftheconfigurationmenuonthe
display.
Themenuconsistsof
}
Messagesatcoldstart,ifthereareproblemswiththechipcard.
}
Level1:Statusindicators,errorstack
}
Level2:Passwordentry
}
Level3:Configuration
Thedisplayedsymbolsillustratetheoperationoftherotaryknob.
Rotateknob
Pressknob
Level1and2:Statusindicatorsandpasswordentry
Statusinformationisdisplayedwhenthedeviceisswitchedon.Thislevelisnotpassword
protected.
Thestateofthesignalsisdisplayedasfollows:
Icon Description
Signalinactive
Signalactive
ThepasswordisenteredinLevel2.ItauthorisesconfigurationofthedeviceinLevel3.
