Operation
OperatingManualPNOZs50
1002194EN02
49
7.1.2 Display
7.1.2.1 Errorstackentries
Upto32statusanderrormessagesarestored.Theycanbecalledupviathedisplay(see
chapterentitled"Commissioning",under"Statusdisplayandconfiguration").
Thefollowinginformationisshownonthedisplay:
}
Sequentialnumberofanerrorstackentry(1...32)
}
Errornumber
}
Errorcategory
}
Upto3parameterstooneerrorentry
}
Timestamp:Timesincesystemstart("PowerOn")
}
Errortext
– Errorsthatcanberectifiedbytheuseraredescribedinthefollowinglist
Remedy:Rectifyerror;ifnecessary,contactPilz
– Internalerrors(systemerrors,allerrorsthatarenotdescribedinthelist)
Remedy:Switchdeviceonandofftorestartit;contactPilziftheerrorreappears
7.1.2.2 Currenterrormessages
}
Allerrorsleadtoasafecondition.
}
Ifanerrorisdetected,the"I/OFault"or"Fault"LEDwilllightuponthedevice:
– "I/OFault":Faultatinputsoroutputs.Faultthatcanberepairedbytheuserleading
tosafecondition.
– "Fault":Internalerrorleadingtoasafecondition.
}
Anerrorisenteredintheerrorstack(seeerrorstack).
}
Themostrecenterrormessageisshownonthedisplay.
}
Oncetheerrorhasbeenrectifiedandrestarted,theerrormessageisretainedintheer
rorstack.
Listoftheerrorsthatcanberectifiedbytheuser
INFORMATION
Errorsuptoerrorcategory27canberectifiedbytheuser.Allothererrors
areinternalerrors.The"Fault"LEDwilllightinthecaseofinternalerrors.
Restartthedevice.ContactPilziftheerrorreappears.
