Commissioning
OperatingManualPNOZs50
1002194EN02
29
WARNING!
Electricshock!
Safeelectricalisolationmustbeensuredfortheexternalpowersupplythat
generatesthesupplyvoltage.Failuretodosocouldresultinelectricshock.
ThepowersuppliesmustcomplywithEN609501,05/2006,EN6155826,
11/1997.
INFORMATION
Max.currentatthepowercircuits
ItisessentialtonotethattheeffectivecurrentatterminalsB1/B2tosupply
thepowercircuitsmustnotexceed10A.Thecablesmustbefittedwitha
10Afuse,characteristicB/C.
Supplyvoltageforpowercir
cuits
Pleasenote:Thesupply
voltagemustbeprotected
withafuse.
FuseF1:
Circuitbreaker24V,48
VDC,10A,characteristicB/
C
L3
L1
L2
PE
B1
B2
L+
L-
F1
6.1.5 Powercircuit
Powercircuit
Dualpoleoutputs
O1+
O1-
O2+
O2-
